Description:

The OPB930 and OPB940 series of Photologic® photo integrated circuit switches provide optimum flexibility for the design engineer. Building from a standard housing with a 0.125" (3.18 mm) wide slot, a user can specify the type and polarity of TTL output, discrete shell material, aperture width and either 0.350" (8.9 mm) long pins (L Series) or 24" (610 mm) AWG, UL listed wire leads (W Series). All housings are made from an opaque grade of injection-molded plastic that minimizes the assembly’s sensitivity to both visible and near-infrared ambient radiation. Discrete shells (exposed on the parallel faces inside the device throat) are either IR transmissive plastic (for applications where aperture contamination may occur) or opaque plastic (for maximum protection against ambient light). Electrical output can be specified as either TTL Totem Pole or TTL Open Collector, either of which can be supplied with buffer or inverter output polarity. All devices have the added stability of a built-in hysteresis amplifier. Custom electrical, wire and cabling and connectors are available. Contact your local representative or OPTEK for more information.

Features:

? Choice of aperture size ? Choice of output configurations

? Choice of opaque or IR transmissive shell

? Choice of pins (L) or wires (W)

? 0.125" (3.18 mm) slot width

? 0.320" (8.128 mm) lead spacing for PCBoard (side mounting)

? Data rates to 250 kBaud

Applications:

? Mechanical switch replacement

? Speed indication (tachometer)

? Mechanical limit indication

? Edge sensing

OPB930和OPB940系列Photologic®光電集成電路開關為設計工程師提供了最佳靈活性。從帶有0.125英寸（3.18毫米）寬插槽的標準外殼構建，用戶可以TTL輸出的類型和極性、離散外殼材料、孔徑寬度以及0.350英寸（8.9毫米）長引腳（L系列）或24英寸（610毫米）AWG、UL認證導線（W系列）。所有外殼均由不透明等級的注塑塑料制成，可最大限度地降低組件對可見光和近紅外環境輻射的敏感性。分立外殼（暴露在設備喉部?jī)?nèi)的平行面上）為紅外透射塑料（用于可能發生孔徑污染的應用）或不透明塑料（用于大程度地保護環境光）。電氣輸出可以為T(mén)TL圖騰極或TTL開路集電極，其中任何一個都可以提供緩沖或逆變器輸出極性。所有設備都具有內置滯后放大器的額外穩定性。可定制電氣、電線和電纜以及連接器。有關更多信息，請聯系當?shù)卮砘騉PTEK。

特征：

? 孔徑大小的選擇? 輸出配置的選擇

? 不透明或紅外透射外殼的選擇

? 引腳（L）或?qū)Ь€（W）的選擇

? 0.125英寸（3.18毫米）槽寬

? PCB板的0.320英寸（8.128毫米）引線間距（側面安裝）

? 數據速率高達250 kBaud

光電集成電路開關應用：

? 機械開關的更換

? 速度指示（轉速表）

? 機械極限指示

? 邊緣檢測
